LogTag TREX-8 - Data logger with external probe


The LogTag Remote Probe Temperature Recorder measures and stores up to 8000 temperature readings over -40°C to +99°C (-40°F to +210°F) measurement range. Using the LogTag Interface and LogTag’s freely available companion software LogTag Analyser , the LogTag is easily set-up for recording conditions including delayed start, sampling interval, number of readings, continuous or fixed number of readings and configuration of conditions to activate the ALERT

Readings are downloaded using LogTag Analyser which provides facilities for charting, zooming, listing data statistics and allows exporting the data to other applications such as Excel.

Applications: All standard temperature recording applications where an external probe is beneficial


Alert & OK Indicator indicates if still recording and if readings within configured limits

Inspection mark in log by push button

Push Button Logging start with optional delayed start or specific Time & Date start

Rapid Download! Takes only seconds to download recordings

Thin Flat Case -  Fits easily into packaging and thin enough to be easily mailed “letter rate

High performance at low cost

Real time clock records time & temperature simultaneously

Easy to use LogTag Analyser software that runs on any PC configures LogTag for recording then downloads resulting data for analysis. Data can also be exported to fomats compatible with other applications such as Excel

Interchabgeable Probes LogTag remote temperature probes are interchangeable provided they are changed with LogTag ST100 type remote temperature sensors

Applications: Ideal for cost-effective monitoring of temperature sensitive goods in both short haul and long-distance transportation applications

LogTag TREX-8 Specifications

Temperature range -40°C … +99°C

Accuracy up to ±0.5°C

8,000 logs

Smallest sampling frequency 30 seconds

Up to 3 years typical battery operating life

choice of 1.5m or 3.0m external probes with PTFE cable, SS316 tips (food rated) and gold plated connector

Technical Specifications ...
